Introduction


When deployed in smaller or larger military formations the need to exchange timely C2 information between coalition forces is essential. However, import and export of data is a vital issue and needs your highest attention as many procedures and regulations must be met. Typically, right classification, markings, releaseability, formats, origin of data etc. must always be verified and checked before data release/ exchange. Other types of information exchanges must be done timely – to be valid – such as blue force tracking and cross domain call for fire. In both cases a full set of security procedures must be set up and followed. Validations and checks to meet your security profile, could be, release procedures (two factor release), data content validation, validation of signing, classification, and other filters like multiple virus scanning. The Arbit C4ISR gateway will support and automate your data management as your trusted gateway for import and export of data, supporting both automated and manual release and import of data.

Arbit C4ISR Gateway is built on hardware based Data Diode technology and therefore offers a continued network separation with no backflow possible. The Arbit C4ISR gateway can be delivered in two variants – a server room version and a ruggedized version (only hardware is different). The ruggedized C4ISR getaway is designed and build to operate in the battlefield under the most challenging conditions. All units are 1U 19”/2 and a full gateway is only 3U (UPS and power supply excluded) equipped with NATO standard connectors and designed for vehicle mount.

Cross Domain Solutions

Cross Domain Solutions


- OR -


Capabilities

The Arbit C4ISR Gateway


The Arbit C4ISR Gateway is by design build as a platform, enabling different security profiles to be implemented. For the C4ISR platform Arbit offers a range of filters and add ons. However, the most important feature is that the robust and open API of the Gateway allows you to program and build your national security profile independent from any contractor support. This is the highest level of security you can get - you own data and processes.

Verification of Data Signatures

The Gateway uses signing technology to securely identify the source of the released data. Only approved source systems or individuals can sign data which then is allowed to pass through the gateway.

Logging

Full audit log and syslog.

Two factor authentications

Supports signing as standard + NATO Clearing house functions like Releasing and Clearing officer.

Security certification

The Target of Evaluation (TOE) ensures NO backflow possible.

Malware protection

As a OPSWAT partner the C4ISR Gateway integrates with OPSWAT Metadefender and - CDR.

Supported protocols

S/MIME mail integration, SitaWare, MIPS, ASCA and SYSTEMATIC one-way communication.

API

Open API for building custom content filters (C++ and Java).

Working climate / Tested Environments

Temperature shock, salt/fog, vibration, EMC/EMI Environment.

Power

Both Gateway and Data Diode will run on 12-24 Volt, Server < 200w, Diode < 170W full Gateway less than 800W.

Size

Based on 1U, 19"/2 components. Data diode 1U 2x19"/2 units, Server 1U 1x19"/2, Full gateway 3U 19".


Download datasheet for The Arbit C4ISR gateway


Download PDF
